4K3N | pdb_00004k3n

Phosphonic Arginine Mimetics as Inhibitors of the M17 Aminopeptidases from Plasmodium falciparum


Experimental Data Snapshot

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.00 Å
  • R-Value Free:
    0.240 (Depositor), 0.240 (DCC)
  • R-Value Work:
    0.196 (Depositor), 0.210 (DCC)
  • R-Value Observed:
    0.199 (Depositor)

Starting Model: experimental
View more details

wwPDB Validation   3D Report Full Report


Ligand Structure Quality Assessment

Created with Raphaël 2.3.0Worse 01 BetterLigand structure goodness of fit to experimental dataBest fitted 1OTClick on this verticalbar to view details

This is version 1.2 of the entry. See complete history


Literature

Synthesis and Structure-Activity Relationships of Phosphonic Arginine Mimetics as Inhibitors of the M1 and M17 Aminopeptidases from Plasmodium falciparum.

Kannan Sivaraman, K.Paiardini, A.Sienczyk, M.Ruggeri, C.Oellig, C.A.Dalton, J.P.Scammells, P.J.Drag, M.McGowan, S.

(2013) J Med Chem 56: 5213-5217

  • DOI: https://doi.org/10.1021/jm4005972
  • Primary Citation of Related Structures:
    4K3N, 4K5L, 4K5M, 4K5N, 4K5O, 4K5P

  • PubMed Abstract:

    The malaria parasite Plasmodium falciparum employs two metallo-aminopeptidases, PfA-M1 and PfA-M17, which are essential for parasite survival. Compounds that inhibit the activity of either enzyme represent leads for the development of new antimalarial drugs. Here we report the synthesis and structure-activity relationships of a small library of phosphonic acid arginine mimetics that probe the S1 pocket of both enzymes and map the necessary interactions that would be important for a dual inhibitor.


  • Organizational Affiliation

    Department of Biochemistry and Molecular Biology, Monash University, Clayton Campus, Melbourne, VIC 3800, Australia.


Macromolecules
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 1
MoleculeChains Sequence LengthOrganismDetailsImage
M17 leucyl aminopeptidase
A, B, C, D, E
528Plasmodium falciparum 3D7Mutation(s): 3
Gene Names: LAPPF14_0439
EC: 3.4.13 (UniProt), 3.4.11.1 (UniProt)
UniProt
Find proteins for Q8IL11 (Plasmodium falciparum (isolate 3D7))
Explore Q8IL11
Go to UniProtKB:  Q8IL11
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupQ8IL11
Sequence Annotations
Expand
  • Reference Sequence
Small Molecules
Ligands 6 Unique
IDChains Name / Formula / InChI Key2D Diagram3D Interactions
2PE
Query on 2PE

Download Ideal Coordinates CCD File
BA [auth B]
CA [auth B]
DD [auth J]
HB [auth E]
IC [auth H]
NONAETHYLENE GLYCOL
C18 H38 O10
YZUUTMGDONTGTN-UHFFFAOYSA-N
1OT
Query on 1OT

Download Ideal Coordinates CCD File
BB [auth E]
GA [auth C]
GC [auth H]
HD [auth K]
LB [auth F]
{(R)-amino[4-(1H-pyrazol-1-yl)phenyl]methyl}phosphonic acid
C10 H12 N3 O3 P
KEKSMECJAGVZSC-SNVBAGLBSA-N
1PE
Query on 1PE

Download Ideal Coordinates CCD File
AC [auth G]
AD [auth J]
BC [auth G]
BD [auth J]
CC [auth G]
PENTAETHYLENE GLYCOL
C10 H22 O6
JLFNLZLINWHATN-UHFFFAOYSA-N
SO4
Query on SO4

Download Ideal Coordinates CCD File
AA [auth B]
CB [auth E]
DB [auth E]
HA [auth C]
HC [auth H]
SULFATE ION
O4 S
QAOWNCQODCNURD-UHFFFAOYSA-L
ZN
Query on ZN

Download Ideal Coordinates CCD File
AB [auth E]
DA [auth C]
DC [auth H]
ED [auth K]
FA [auth C]
ZINC ION
Zn
PTFCDOFLOPIGGS-UHFFFAOYSA-N
CO3
Query on CO3

Download Ideal Coordinates CCD File
EA [auth C]
EC [auth H]
FD [auth K]
JB [auth F]
LC [auth I]
CARBONATE ION
C O3
BVKZGUZCCUSVTD-UHFFFAOYSA-L
Experimental Data & Validation

Experimental Data

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.00 Å
  • R-Value Free:  0.240 (Depositor), 0.240 (DCC)
  • R-Value Work:  0.196 (Depositor), 0.210 (DCC)
  • R-Value Observed: 0.199 (Depositor)
Space Group: P 21 21 21
Unit Cell:
Length ( Å )Angle ( ˚ )
a = 173.716α = 90
b = 177.079β = 90
c = 229.185γ = 90
Software Package:
Software NamePurpose
Blu-Icedata collection
PHASERphasing
PHENIXrefinement
MOSFLMdata reduction
SCALAdata scaling

Structure Validation

View Full Validation Report



Ligand Structure Quality Assessment

Created with Raphaël 2.3.0Worse 01 BetterLigand structure goodness of fit to experimental dataBest fitted 1OTClick on this verticalbar to view details

Entry History

Deposition Data

  • Released Date: 2013-06-12
  • Deposition Author(s): McGowan, S.

Revision History  (Full details and data files)

  • Version 1.0: 2013-06-12
    Type: Initial release
  • Version 1.1: 2013-07-24
    Changes: Database references
  • Version 1.2: 2023-09-20
    Changes: Data collection, Database references, Derived calculations, Refinement description
