3RD3 | pdb_00003rd3

Structure of Pseudomonas aeruginosa transcriptional regulator PA2196

Experimental Data Snapshot

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.40 Å
  • R-Value Free:
    0.295 (Depositor), 0.296 (DCC)
  • R-Value Work:
    0.217 (Depositor), 0.215 (DCC)
  • R-Value Observed:
    0.221 (Depositor)

wwPDB Validation   3D Report Full Report


This is version 1.1 of the entry. See complete history.


Literature

Structure of Pseudomonas aeruginosa transcriptional regulator PA2196

Choe, J., Kang, Y.

To be published.

Macromolecules
Find similar proteins by:
(by identity cutoff)  |  3D Structure
Entity ID: 1
MoleculeChains Sequence LengthOrganismDetailsImage
Probable transcriptional regulator
A, B
197Pseudomonas aeruginosaMutation(s): 0
Gene Names: PA2196
UniProt
Find proteins for Q9I1S1 (Pseudomonas aeruginosa (strain ATCC 15692 / DSM 22644 / CIP 104116 / JCM 14847 / LMG 12228 / 1C / PRS 101 / PAO1))
Explore Q9I1S1
Go to UniProtKB:  Q9I1S1
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupQ9I1S1
Sequence Annotations
Expand
  • Reference Sequence
Experimental Data & Validation

Experimental Data

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.40 Å
  • R-Value Free:  0.295 (Depositor), 0.296 (DCC)
  • R-Value Work:  0.217 (Depositor), 0.215 (DCC)
  • R-Value Observed: 0.221 (Depositor)
Space Group: P 1 21 1
Unit Cell:
Length ( Å )Angle ( ˚ )
a = 60.396α = 90
b = 45.589β = 109.72
c = 66.84γ = 90
Software Package:
Software NamePurpose
REFMACrefinement
PDB_EXTRACTdata extraction
HKL-2000data collection
HKL-2000data reduction
HKL-2000data scaling
MOLREPphasing

Structure Validation

View Full Validation Report



View more in-depth experimental data
Entry History

Deposition Data

Revision History  (Full details and data files)

  • Version 1.0: 2012-04-04
    Type: Initial release
  • Version 1.1: 2024-11-20
    Changes: Data collection, Database references, Structure summary
