5F32

Crystal structure of human KDM4A in complex with compound 40


Experimental Data Snapshot

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.05 Å
  • R-Value Free: 0.203
  • R-Value Work: 0.168
  • R-Value Observed: 0.170

Starting Model: experimental
View more details

wwPDB Validation   3D Report Full Report


Ligand Structure Quality Assessment


This is version 1.3 of the entry. See complete history


Literature

8-Substituted Pyrido[3,4-d]pyrimidin-4(3H)-one Derivatives As Potent, Cell Permeable, KDM4 (JMJD2) and KDM5 (JARID1) Histone Lysine Demethylase Inhibitors.

Bavetsias, V.Lanigan, R.M.Ruda, G.F.Atrash, B.McLaughlin, M.G.Tumber, A.Mok, N.Y.Le Bihan, Y.V.Dempster, S.Boxall, K.J.Jeganathan, F.Hatch, S.B.Savitsky, P.Velupillai, S.Krojer, T.England, K.S.Sejberg, J.Thai, C.Donovan, A.Pal, A.Scozzafava, G.Bennett, J.M.Kawamura, A.Johansson, C.Szykowska, A.Gileadi, C.Burgess-Brown, N.A.von Delft, F.Oppermann, U.Walters, Z.Shipley, J.Raynaud, F.I.Westaway, S.M.Prinjha, R.K.Fedorov, O.Burke, R.Schofield, C.J.Westwood, I.M.Bountra, C.Muller, S.van Montfort, R.L.Brennan, P.E.Blagg, J.

(2016) J Med Chem 59: 1388-1409

  • DOI: https://doi.org/10.1021/acs.jmedchem.5b01635
  • Primary Citation of Related Structures:
    5F2S, 5F2W, 5F32, 5F37, 5F39, 5F3C, 5F3E, 5F3G, 5F3I, 5F5A, 5F5C, 5F5I, 5FPL

  • PubMed Abstract:

    We report the discovery of N-substituted 4-(pyridin-2-yl)thiazole-2-amine derivatives and their subsequent optimization, guided by structure-based design, to give 8-(1H-pyrazol-3-yl)pyrido[3,4-d]pyrimidin-4(3H)-ones, a series of potent JmjC histone N-methyl lysine demethylase (KDM) inhibitors which bind to Fe(II) in the active site. Substitution from C4 of the pyrazole moiety allows access to the histone peptide substrate binding site; incorporation of a conformationally constrained 4-phenylpiperidine linker gives derivatives such as 54j and 54k which demonstrate equipotent activity versus the KDM4 (JMJD2) and KDM5 (JARID1) subfamily demethylases, selectivity over representative exemplars of the KDM2, KDM3, and KDM6 subfamilies, cellular permeability in the Caco-2 assay, and, for 54k, inhibition of H3K9Me3 and H3K4Me3 demethylation in a cell-based assay.


  • Organizational Affiliation

    Cancer Research UK Cancer Therapeutics Unit, The Institute of Cancer Research , 15 Cotswold Road, London SM2 5NG, U.K.


Macromolecules
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 1
MoleculeChains Sequence LengthOrganismDetailsImage
Lysine-specific demethylase 4A
A, B, C, D
360Homo sapiensMutation(s): 0
Gene Names: KDM4AJHDM3AJMJD2JMJD2AKIAA0677
EC: 1.14.11 (PDB Primary Data), 1.14.11.66 (UniProt), 1.14.11.69 (UniProt)
UniProt & NIH Common Fund Data Resources
Find proteins for O75164 (Homo sapiens)
Explore O75164
Go to UniProtKB:  O75164
PHAROS:  O75164
GTEx:  ENSG00000066135
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupO75164
Sequence Annotations
Expand
  • Reference Sequence
Small Molecules
Ligands 5 Unique
IDChains Name / Formula / InChI Key2D Diagram3D Interactions
5V7
Query on 5V7

Download Ideal Coordinates CCD File
G [auth A],
M [auth B],
S [auth C],
X [auth D]
8-(2-azanyl-1,3-thiazol-4-yl)-3~{H}-pyrido[3,4-d]pyrimidin-4-one
C10 H7 N5 O S
JEHSMTZNFSEDBY-UHFFFAOYSA-N
GOL
Query on GOL

Download Ideal Coordinates CCD File
CA [auth D],
DA [auth D],
J [auth A],
P [auth B]
GLYCEROL
C3 H8 O3
PEDCQBHIVMGVHV-UHFFFAOYSA-N
DMS
Query on DMS

Download Ideal Coordinates CCD File
H [auth A]
N [auth B]
T [auth C]
U [auth C]
Y [auth D]
H [auth A],
N [auth B],
T [auth C],
U [auth C],
Y [auth D],
Z [auth D]
DIMETHYL SULFOXIDE
C2 H6 O S
IAZDPXIOMUYVGZ-UHFFFAOYSA-N
ZN
Query on ZN

Download Ideal Coordinates CCD File
E [auth A]
F [auth A]
K [auth B]
L [auth B]
Q [auth C]
E [auth A],
F [auth A],
K [auth B],
L [auth B],
Q [auth C],
R [auth C],
V [auth D],
W [auth D]
ZINC ION
Zn
PTFCDOFLOPIGGS-UHFFFAOYSA-N
EDO
Query on EDO

Download Ideal Coordinates CCD File
AA [auth D],
BA [auth D],
I [auth A],
O [auth B]
1,2-ETHANEDIOL
C2 H6 O2
LYCAIKOWRPUZTN-UHFFFAOYSA-N
Binding Affinity Annotations
IDSourceBinding Affinity
5V7 BindingDB:  5F32 IC50: 1.15e+4 (nM) from 1 assay(s)
Experimental Data & Validation

Experimental Data

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.05 Å
  • R-Value Free: 0.203
  • R-Value Work: 0.168
  • R-Value Observed: 0.170
  • Space Group: P 1 21 1
Unit Cell:
Length ( Å )Angle ( ˚ )
a = 57.218α = 90
b = 102.593β = 99.29
c = 141.742γ = 90
Software Package:
Software NamePurpose
BUSTERrefinement
XDSdata reduction
Aimlessdata scaling
PHASERphasing
PDB_EXTRACTdata extraction

Structure Validation

View Full Validation Report



Ligand Structure Quality Assessment


Entry History & Funding Information

Deposition Data


Funding OrganizationLocationGrant Number
Cancer Research UKUnited KingdomC309/A11566

Revision History  (Full details and data files)

  • Version 1.0: 2016-01-20
    Type: Initial release
  • Version 1.1: 2016-03-09
    Changes: Database references
  • Version 1.2: 2018-03-07
    Changes: Source and taxonomy
  • Version 1.3: 2024-01-10
    Changes: Data collection, Database references, Derived calculations, Refinement description
